Python and Quantum Programming Workflow

The experiment begins at a clean checkout#

“Works on my machine” usually means the machine is an undocumented input. Remove it. The starting condition is a commit identifier, an unmodified working tree, a supported Python version, and a dependency lock whose hash is recorded before installation. The command must run from a named directory; relative paths and environment variables are part of its interface. Wall-clock time is reported in seconds, not as “fast,” and shots are a count, not a precision label.

The core companion package deliberately uses the Python standard library. Optional SDK adapters live outside that core because Qiskit’s supported execution interfaces are versioned software, not laws of quantum mechanics [Qiskit documentation]. Cirq has its own circuit, simulator, and result conventions and must be pinned independently [Cirq documentation]. A lock should be regenerated intentionally, reviewed as code, and tied to an API review date.

repository: quantum-end-to-end
commit: <40-hex-character revision>
python: 3.13.x
lock_sha256: <64 hex characters>
command: PYTHONPATH=src python -m quantum_end_to_end bell --shots 10000 --seed 7
cwd: labs

A portable circuit representation can help, but it has a boundary. OpenQASM 3 specifies circuit and control semantics subject to implementation support; it does not standardize an SDK’s Python objects, package resolver, displayed bit order, or backend calibration [OpenQASM 3 specification].

Invariant fixtures, adapters, and run records#

Put three concerns in three places. An invariant fixture states what the circuit means: the Bell preparation has exact support on 00 and 11 and zero support on 01 and 10 when q0 is displayed as the most-significant bit. An adapter translates that contract into one SDK. A run record stores what one execution did. If an adapter changes, the fixture does not. If finite-shot counts move, the exact fixture does not.

The record needs enough evidence to falsify the claim: code and input hashes, interpreter and dependency versions, adapter and backend identity, transpiled representation where applicable, seed, shots, exact oracle, statistical acceptance rule, stdout or raw result, duration, and known omissions. ACM’s artifact framework distinguishes availability, functionality, reusability, and reproducibility; placing a zip online establishes only the first dimension [ACM artifact review guidance].

One Bell run, recorded end to end#

The ideal state after Hadamard on q0 and CNOT(q0,q1) is

That equation yields exact probabilities 0.5, 0, 0, 0.5 in displayed order. It does not yield an exact 5,000/5,000 histogram. The seeded sampler makes the book’s transcript deterministic for regression purposes, while its scientific interpretation remains stochastic. The record must preserve both layers rather than replacing the probability oracle with one lucky histogram.

import hashlib, json
REQUIRED = {"python": str, "seed": int, "shots": int, "backend": str,
            "support": dict, "command": str}
def validate_record(record):
    errors = [name for name, kind in REQUIRED.items()
              if name not in record or type(record[name]) is not kind]
    support = record.get("support", {})
    if (record.get("shots", 0) <= 0 or not support or
            any(type(value) not in (int, float) or value < 0 for value in support.values()) or
            abs(sum(support.values()) - 1.0) > 1e-12):
        errors.append("shots_or_support")
    if errors:
        raise ValueError(",".join(sorted(set(errors))))
    payload = json.dumps(record, sort_keys=True, separators=(",", ":")).encode()
    return {"digest": hashlib.sha256(payload).hexdigest(),
            "outcomes": sorted(support), "probability_mass": sum(support.values())}

record = {"python": "3.13", "seed": 7, "shots": 10_000,
          "backend": "quantum_end_to_end.Statevector",
          "support": {"00": 0.5, "11": 0.5},
          "command": "PYTHONPATH=src python -m quantum_end_to_end bell --shots 10000 --seed 7"}
baseline = validate_record(record)
changed_seed = validate_record({**record, "seed": 8})
missing_rejected = False
try:
    validate_record({key: value for key, value in record.items() if key != "command"})
except ValueError:
    missing_rejected = True
assert baseline["outcomes"] == ["00", "11"] and baseline["probability_mass"] == 1.0
assert baseline["digest"] != changed_seed["digest"] and missing_rejected
print(f"PASS: 36 run record digest7={baseline['digest'][:12]} digest8={changed_seed['digest'][:12]} missing_command={missing_rejected}")

Failure drill: version drift versus semantic error#

Version drift fails before or at the adapter boundary: an import moved, a result field changed, a backend option disappeared, or the lock no longer resolves on a supported interpreter. Preserve the traceback, installed versions, and failing adapter test. Do not “repair” the circuit oracle to make an SDK migration green.

A semantic error survives installation but violates the invariant fixture. A classic example is reversing the display convention: the SDK may return classical bits in a native order different from the book’s q0-most-significant strings. The fix belongs in normalization, with a truth-table test. Evidence differs: an environment fault is diagnosed by dependency and API records; a semantic fault is diagnosed by exact support, ordering, and circuit hashes.

The minimum publishable Python artifact#

CI should start from the lock, run the stable suite, validate record schemas, regenerate hashes, and compare deterministic transcripts. A probabilistic claim needs a predeclared acceptance interval rather than byte equality. Optional adapters that cannot install must be reported as blocked or expired, not silently skipped. A publishable artifact also includes a license and tells the reviewer what the suite does not prove.

Treat the run record as an append-only observation, not a cache to be overwritten. A rerun under a new interpreter receives a new record and points back to the circuit fixture it tested. That preserves a useful distinction: identical source hashes with different dependency hashes diagnose environment sensitivity; different source hashes are a new experiment. CI can then compare records field by field and refuse the seductive but meaningless verdict that two JSON files are “close enough.”

The controlled failure belongs in the published evidence. In the drift branch, change only the declared dependency constraint and keep the commit, command, seed, shots, and Bell oracle fixed. A resolver or import failure is then an environment result. In the semantic branch, keep the environment fixed and reverse the bit normalization for an asymmetric fixture; that run should install cleanly and fail the oracle. These failures occupy different layers, so a reader can reproduce both without guessing what the author changed.

The boundary here is deliberate. This chapter establishes repository and evidence structure; it does not derive the state-vector implementation, and it does not nominate Qiskit, Cirq, or any one SDK as the book-wide programming model.
